# Vote Aggregation Methods

The paradox of voting is the coexistence of coherent individual valuations and a collectively incoherent choice by majority rule. In an election with three or more alternatives (candidates, motions, etc.) and three or more voters, it may happen that when the alternatives are placed against each other in a series of paired comparisons, no alternative emerges victorious over each of the others: Voting fails to produce a clear-cut winner.

William H. Riker, 1982 [86]

The paradox of voting was discovered over 200 years ago by M. Condorcet, a French mathematician, philosopher, economist, and social scientist. However, it received little attention until Duncan Black [13] explained its significance in a series of essays he began in the 1940s. The importance of the voting paradox was not fully realized until several years after Kenneth Arrow published Social Choice and Individual Values [3] in 1951, which contained his General Possibility Theorem. The essence of this theorem is that there is no method of aggregating individual preferences over three or more alternatives that satisfies several conditions of fairness and always produces a logical result. Arrow's precisely defined conditions of fairness and logicality have been the subject of scrutiny by other scholars. However, none have found a way of relaxing one or more of these conditions that results in a generally satisfactory voting system immune from the voting paradox. Thus Arrow's theorem has the profound implication that in many situations there is no fair and logical way of aggregating individual preferences -- there is no way to determine accurately the collective will of the people.

Social choice theorists have invented many vote aggregation systems and have attempted to determine the most appropriate systems for a variety of voting situations. Although there is some agreement about which characteristics are desirable in a vote aggregation system, there is much disagreement as to which characteristics are most important. In addition, the selection is often influenced more by political circumstances than by the advice of theorists. Thus the popularity of a voting system is not necessarily an indication of its fairness [66].

The choice of a vote aggregation system can influence much more than the results of an election. It can also influence the ability of analysts to interpret election results, and in turn the ability of representatives to understand the wishes of the people they represent and the satisfaction of the electorate that they have had the opportunity to express themselves. This is due to the fact that the various vote aggregation systems require voters to supply varying amounts of information about their preferences and that some systems tend to encourage voters to report their preferences insincerely. In addition, the choice of vote aggregation system could affect the stability of a government, the degree to which an organization embraces or resists change, and the extent to which minorities are represented. It could also affect the ability of the members of an organization to achieve compromise.

This section explores the many types of vote aggregation systems that have been proposed. Throughout this section the term voting system will refer specifically to the vote aggregation component of a voting system. Section  introduces criteria with which voting systems may be evaluated. Section  discusses majority rule voting and several majoritarian voting methods. Section  describes three positional voting methods. Section  introduces several multi-stage voting methods which are based on majoritarian and positional methods. Section  discusses several types of utilitarian voting methods. Section  introduces proportional and semiproportional voting systems, which are positional systems for electing multiple representatives in proportion to their support in the electorate. The vote aggregation systems described in this chapter are summarized in Figure , at the end of Section 2.1.1.

## Evaluation Criteria

Many criteria have been proposed for evaluating voting systems. Because it is not possible to satisfy all criteria simultaneously, there has been much debate among theorists and political reformists as to which criteria are most important. Some of the most commonly cited criteria are introduced here.

### The Condorcet Criterion

The Condorcet winner is an alternative that beats or ties all others in a series of pairwise contests. The Condorcet criterion holds for a voting system if it selects the Condorcet winner whenever one exists.

Voting systems that do not always select the Condorcet winner can be evaluated in terms of their Condorcet efficiency -- the percentage of elections in which the Condorcet winner is selected (assuming there is a Condorcet winner).

Although the Condorcet criterion is a popular means for evaluating voting systems, there are some situations in which it is not clear that the Condorcet winner represents the collective choice. For example, Fishburn [46] presents a scenario in which five voters must choose between five alternatives (a, b, c, d, e). The voters hold the following preference orderings (listed from most preferred to least preferred):

Given this preference profile, a is the Condorcet winner. However, an examination of the number of times each alternative is ranked first, second, etc., bears the following results:

In an examination of rankings, b appears to be the best choice -- with equal first ranks to a and more second and third ranks than a -- yet the Condorcet winner is a.

### Consistency

A voting system is consistent if when the electorate is divided arbitrarily into two parts and separate elections in each part result in the same alternative being selected, an election of the entire electorate also selects that alternative. If a voting system is not consistent than it may be manipulated through the establishment of strategically configured election districts.

### The Implementation Criteria

The implementation criteria evaluate the ease with which voters may specify their preferences and election administrators may aggregate these preferences. The more information required of the voter, the more difficult the voting procedure from the voter's perspective. The more comparisons that must be done in the aggregation process, the more difficult the voting procedure from the administrator's perspective [77].

In cases where the electorate is educated, even the most complicated voting systems are unlikely to pose difficulties for most voters. However, a simple voting procedure may be very important when parts of the electorate are illiterate. In addition, regardless of the literacy of the electorate, any voting system that requires multiple rounds of balloting is likely to be problematic unless the electors are assembled for a meeting.

The advent of high-speed computers diminishes the significance of the number of comparisons necessary to count the votes. Once an important factor for determining the practicality of a voting system, this implementation criterion is now largely irrelevant in most situations where votes are tallied by computer. However, this criterion remains relevant for voting systems in which determining the winner is NP-hard [9]. Another criterion related to system implementation is anonymity. Although most systems can be implemented with secret ballots just as easily as they can be implemented with non-secret ballots, some procedures require action on the part of the voter after initial balloting and thus may be difficult to implement with secret ballots. Cryptographic electronic voting (to be discussed in Section ) and commerce protocols may provide solutions to this problem.

### Independence from Irrelevant Alternatives

A voting system is independent from irrelevant alternatives if it always produces the same results given the same profile of ordinal preferences. This criterion has consequences in two areas: it prohibits voting systems that take into account cardinal preferences or ordinal preferences beyond each voter's first choice, and it prohibits voting systems that include elements of randomness [86].

To understand the first consequence, it is important to realize that it applies to subsets of alternatives. Thus if a group of voters reverse their preference ordering for two alternatives, no change should occur in the outcome with respect to another set of alternatives for which the profiles remain fixed. The same applies to changes in intensity of preferences. Thus voting systems that use cardinal preferences are not independent because a change in intensity of preference for a loosing alternative may render it a winning alternative, even if the voters who changed their cardinal preferences do not change their ordinal preferences.

The first consequence of the independence criterion can also be understood by considering Vickrey's definition: ``The social choice between any two alternatives shall not be affected by the removal or addition of other alternatives to the field of feasible alternatives under consideration'' [103]. Arrow gave as an example a situation in which a losing candidate dies after the ballots have been cast. If the voting system is independent, removing that candidate's name (and votes) from the ballots should not change the election winner [3]. If each ballot contains only the name of the voter's most preferred candidate (or an unordered set of preferred candidates), votes for the deceased would be eliminated and the vote totals for the surviving candidates would remain unchanged. However, if the ballots contain an ordinal preference ranking over two or more candidates, those ballots containing votes for the deceased would be recounted with the surviving candidates who are ranked below the deceased bumped up.

The fact that the independence criterion allows voting systems that use minimal information about voter preferences while prohibiting voting systems that take into account more information about voter preferences has made it controversial. Use of this criterion is generally motivated by the fact that it prohibits voting systems that use information that may be considered arbitrary (cardinal preferences) or that tend to promote strategic behavior. However, some theorists argue that in the absence of a perfect voting system, systems that require voters to supply cardinal preferences or ordinal preferences over multiple alternatives should not be ruled out because of a lack of independence [72, 103]. One might also argue that the systems that satisfy the independence criterion do so because they ignore information and essentially waste the votes of all those who do not support one of the top contenders. Thus those who support the ``irrelevant'' alternatives (those alternatives with little chance of winning) might as well not vote at all. Indeed these systems also promote strategic behavior because they tend to encourage supporters of the irrelevant alternatives to vote for second-choice alternatives with better chances of winning.

The second consequence of the independence criterion is to prohibit voting systems that do not have stable outcomes: that is, voting systems in which a given set of ballots may produce different results each time it is counted. Instability is rarely encountered in the traditional voting systems discussed in the chapter and has not been the subject of much discussion in the literature. It is generally taken for granted that voting systems should not involve random processes, except possibly to to resolve ties. Slaton offers an interesting explanation of this assumption using Newtonian and quantum physics as metaphors. She argues that traditional voting systems stem from a Newtonian world view in which it is believed that the world can be understood through the study of discreet particles whose behavior adheres to strict laws. She contrasts the Newtonian philosophy with the quantum philosophy, which places less emphasis on absolutes and more emphasis on tendencies. Random sampling is thus a reasonable approach to selecting representatives under a quantum world view [96].

### Monotonicity

A voting system is monotonic if when a voter raises the valuation for a winning alternative it remains a winning alternative, and when a voter lowers the valuation for a losing alternative it remains a losing alternative. All voting systems that eliminate alternatives prior to selecting a winner violate monotonicity [86].

If is a system is not monotonic, a situation may arise in which voters could prevent their favorite alternative from winning by voting for that alternative. Obviously this is contrary to the purposes of a voting system -- voters should not be penalized for supporting their favorite alternative.

### Neutrality

A voting system is neutral if the system does not favor any alternative. Although it may seem obvious that voting systems should be neutral, some are designed specifically not to be neutral in order to promote government stability or ensure that a decision is made. In fact, many systems that have tie-breaking rules that do not employ a random choice violate neutrality. For example, parliamentary voting systems in which ``yea'' and ``nay'' votes are taken generally favor the nay side in the event of a tie. Thus they are biased towards the nay alternative and are not neutral.

### Pareto Optimality

A voting system is Pareto-optimal if when every voter prefers alternative x to alternative y, alternative y is not selected. This criterion is similar to the monotonicity criterion, but is more often satisfied by the voting systems that have been proposed. It is sometimes referred to as the unanimity criterion.

Both Pareto-optimality and monotonicity relate to the collective rationality of a group decision-making procedure. Clearly if one were to make a decision based entirely on one's own preferences, one would not select y if one preferred x. The rational individual would select an alternative other than y (x or an alternative preferred to x). Likewise if one had selected x and later received news that x was even better than originally thought or that y was even worse than originally thought, one would not switch the selection to y. The rational individual would stick with the selection of x. When many decision-makers must make a group decision, we can extend the rules we would follow for individual decision-making. Thus if every decision-maker prefers x to y then it would be irrational for the group as a whole to select y. Likewise, if the group selects x and one or more group members decide that x is even better than originally thought or y is even worse than originally thought, the group should not change its decision. Thus with Pareto-optimality and monotonicity, the notion of what is individually rational can be extended easily to what is collectively rational.

### Proportionality

Voting systems that elect multiple representatives may be evaluated in terms of the correspondence between the number of representatives elected from each party and the support for each party in the electorate. Some voting systems tend to favor larger parties or smaller parties, while others result in highly proportional representation. In addition to the voting method used, the number of representatives to be elected in each district can have a major impact on the proportionality of a voting system.

Consider the following example. A city council is composed of five representatives, each elected by the voters in a single-member district. Sixty percent of the city's voters are Democrats and 40% are Republicans. The distribution of party membership is fairly even across the five districts. Under this non-proportional representation system, all five representatives elected are Democrats. However, if the five representatives were elected at-large by voters from throughout the city using a proportional representation system, three Democrats and two Republicans would be elected.

Related to proportionality is the average ballot effectiveness. The effectiveness of an individual ballot may be defined as the proportion of a ballot that is used to vote for a candidate that ends up winning. In elections where each voter votes for one candidate and the candidate with the most votes wins, all ballots voting for the winning candidate are 100% effective while the remaining ballots are 0% effective. The more proportional a voting system, the greater its average effectiveness is likely to be.

### Tendency to Encourage Manipulation

Situations sometimes arise in which it is not always in the best interest of voters to vote for their most sincerely preferred alternatives -- for example, in US Presidential elections with three or more candidates, supporters of a third-party candidate often vote for a second choice in order to avoid wasting their votes on a candidate with little chance of getting elected. When voters cast insincere ballots they are said to be voting strategically or manipulating the election. Gibbard [54] and Satterthwaite [94] proved that all non-dictatorial voting systems with at least three possible outcomes are manipulable. However, some voting systems tend to encourage manipulation more than others and situations in which it is advantageous to vote strategically arise more frequently in some systems than in others. Furthermore, it is easier for voters to identify advantageous strategies in some systems than in others. Many social-choice theorists have suggested that the tendency to encourage manipulation is an important criteria for evaluating voting systems [17, 40, 78].

Nurmi evaluates voting systems' tendencies to encourage manipulation in terms of the information required for successful manipulation. He sketches a four-level hierarchy for preference misrepresentation. At the first level of the hierarchy are those systems that require knowledge of only the ``distribution of first preferences over alternatives'' in order to be manipulated. At the second level are those systems that require knowledge of ``distribution of approval over alternatives.'' At the third level are those systems that require knowledge of the ``binary comparison matrix.'' And at the fourth and most difficult to manipulate level are those systems that require knowledge of the ``entire preference profile'' [78].

While Nurmi's hierarchy is helpful in identifying the relative difficulties involved in obtaining the information necessary to manipulate an election, it does not distinguish voting systems based on the ease with which this information may be applied or the chances that this information will reveal preference profiles over which manipulation is possible. Indeed, it has been shown that manipulating some voting systems is an NP-hard problem, even with perfect information about voter preference profiles [8]. Nurmi's hierarchy also fails to distinguish between systems manipulated most successfully by individuals (micromanipulation) and those manipulated most successfully by coalitions (coordinated macromanipulation).

Figure: Properties of vote-aggregation procedures. Check marks indicate properties possessed by the voting system in that row, Xs indicate properties not possessed by the voting system in that row. Cells have been left blank where information is unavailable or varies depending on the specific details of the procedure used.

## Majority Rule and Majoritarian Methods

Majority rule is the simplest of non-dictatorial voting systems. When two alternatives are under consideration, the one preferred by the most voters is selected. However, when three or more alternatives are under consideration, another procedure must be used to narrow down the field of alternatives or ensure that one of the alternatives is preferred by the majority. Majority rule with two alternatives possesses all of the most desirable properties of voting systems. In fact, it is often considered the best method of preference aggregation [86].

Unfortunately, decisions can rarely be considered as a choice between two alternatives unless another mechanism has been used to eliminate all but two alternatives or divide the alternatives into two groups. The two-party system in the United States serves to narrow down the fields of candidates so that only two candidates compete for each office in most state and national elections. Parliamentary procedures generally involve an amendment protocol that results in all votes being binary choices between a new proposal and the status quo or a proposal and an amendment. But when runoff elections or amendment procedures are used to reduce the field of alternatives to two, alternatives may be eliminated that could actually win the election if an alternate procedure were used. Thus when majority rule is used with three or more alternatives, one or more criteria may be violated as a result of the procedure used to narrow down the alternatives. For example, Riker presents a scenario in which monotonicity is violated when 13 voters choose between four alternatives (w, x, y, z). The voters hold the following preference orderings:

Simple majority rule may be applied to three or more alternatives by comparing the alternatives two at a time, eliminating an alternative if it loses a pairwise comparison. However, the order in which alternatives are selected for comparison may determine the outcome of the election. For example, given the above preferences, either w, x, or y might win, depending on what order they are selected for comparison.

Majoritarian methods extend the principles of majority rule for more than two alternatives by selecting the alternative that can beat all other alternatives in pairwise comparisons (the Condorcet winner). However, such an alternative is often non-existent, and these methods must provide additional procedures for selecting a winner in the absence of a Condorcet winner. Because these methods rely on binary comparisons between all candidates, voters must supply their complete preference orderings or the election must be conducted with multiple rounds of balloting [86]. Thus, knowledge of the binary comparison matrix is required for them to be manipulated [78].

Many majoritarian methods have been proposed, most of which are monotonic and result in the selection of the Condorcet winner when one exists. All violate the consistency criterion, and they have differing outcomes in the absence of a Condorcet winner. Except for the amendment procedure, these methods are rarely used. The following examples of majoritarian methods are described by Riker [86] and Nurmi [77].

### The Amendment Procedure

The amendment procedure is widely used for parliamentary and board room voting. This procedure pairs the proposal under consideration with the status quo. If a variation on the proposal is introduced it is paired with the proposal and voted on as an amendment prior to the final vote. If the amendment succeeds, then the amended proposal is eventually paired with the status quo in the final vote. Otherwise, the amendment is eliminated prior to the final vote. This procedure is not neutral because it favors the status quo in the absence of a Condorcet winner.

### The Successive Procedure

Unlike the amendment procedure, the successive procedure is neutral. However it does not select any winner in the absence of a Condorcet winner, and may sometimes select no winner even when a Condorcet winner exists. In this procedure the candidates are considered one at a time until one has received the majority of votes or the list of candidates has been exhausted. After the list has been exhausted the procedure may be repeated (with the hope that some of the voters may change their votes) or another procedure may be used.

### Other Majoritarian Procedures

The Copeland rule selects the alternative with the largest Copeland index, which is the number of times an alternative beats other alternatives minus the number of times that alternative loses to other alternatives when the alternatives are considered in pairwise comparisons. The Copeland rule is Pareto-optimal.

The Schwartz rule selects the set of alternatives over which the collective preferences are cyclic and the entire cycle is preferred over the other alternatives. When there is a Condorcet winner it is the single element in such a set. However, in the absence of a Condorcet winner most or all of the alternatives may be members of this set. The Schwartz rule is not Pareto-optimal.

Other majoritarian procedures include the maximin method, Dodgson's method, and the Kemeny rule. Determining the winner using Dodgson's and Kemeny's procedures is NP-hard [9]. See [77, 78, 86] for descriptions of these procedures.

## Positional Methods

Unlike majoritarian methods, which use only information from binary comparisons between candidates, positional methods take into account information about individuals' preference orderings. However, these methods do not necessarily take into account a voter's entire preference ordering. In this section, three single-stage positional methods are described: plurality voting, which uses only information about each voter's most preferred alternative; approval voting, which uses information about a varying number of top alternatives for each voter; and the Borda count, which uses information about each voter's entire preference ordering. These methods do not necessarily select the Condorcet winner when one exists. In addition, for some sets of voter preference profiles, each method produces a different outcome. The three positional methods described here are all monotonic and Pareto-optimal.

### Plurality Voting

Plurality voting, also referred to as first past the post, is a procedure in which each voter votes for his or her single most preferred alternative (or when n alternatives are to be selected, voters vote for their n most preferred alternatives). The alternative that receives the most votes wins. Because this procedure only takes into account the first choice preference of each voter, it often fails to select the Condorcet winner. As a result it sometimes produces election results which appear illogical when three or more alternatives compete. It sometimes even selects the Condorcet loser, the alternative that is defeated by all others in pairwise comparisons.

In plurality elections with three candidates, two candidates with somewhat similar ideological views will sometimes both lose to a candidate with opposite views. However, after the election the supporters of the two losing candidates may realize that had they worked together and supported a single candidate, that candidate could have won easily. In the next election, these supporters are more likely to compromise and back a single candidate. Thus, over time, plurality voting encourages parties to offer only two candidates -- reducing plurality voting to simple majority rule. Plurality voting is widely used for governmental elections in the United States and has been credited with helping to maintain the two-party system [86].

Plurality voting is classified at the first level of Nurmi's preference misrepresentation hierarchy and is generally considered to be one of the easiest voting systems to manipulate [78].

### Approval Voting

Approval voting, independently developed by at least five sets of people in the mid-1970s, allows voters to vote for (approve of) as many of the alternatives as they wish. Generally, the winner of an approval voting election is the alternative that receives a plurality of votes [17].

Approval voting is currently used by several professional societies, including the Institute of Electrical and Electronics Engineers, the Mathematical Association of America, the American Statistical Association, and The Institute of Management Sciences. It tends to promote the election of moderate candidates and prevent situations in which the candidate elected is ranked last by those who did not vote for him or her. It also tends to encourage three or more alternatives to be considered in an election. If all voters approve of only their first choice alternatives, approval voting results in the same outcome as plurality voting.

Nurmi classifies approval voting at the second level of his preference misrepresentation hierarchy because it requires knowledge of the distribution of approvals over alternatives in order to be manipulated [78]. In addition, Brams and Fishburn assert that approval voting is less likely to be manipulated than plurality voting because it presents voters with fewer situations in which it is advantageous to vote strategically. In many situations where plurality voters would fare better by voting for a second choice, approval voters can maximize their voting power by voting for both their first and second choices [17].

As with plurality voting, approval voting does not necessarily select the Condorcet winner when one exists. However, approval voting has a higher Condorcet efficiency than plurality voting, selecting the Condorcet winner in all cases where it is selected by plurality voting as well as in other cases where it it may not be selected by plurality voting [17].

### The Borda Count

Borda count voting, proposed in 1770 by the French mathematician Jean-Charles de Borda, is a procedure in which each voter forms a preference ranking for all alternatives. Given n alternatives, each voter casts n votes for his or her most preferred alternative, n-1 votes for his or her second most preferred alternative, etc. The alternative that receives the most votes wins [89].

This system, as well as other similar ``scoring'' or ``point'' methods, incorporate all voter preference information into the vote aggregation. However, as with the other positional voting methods, this does not always produce a logical result. In fact, the result of a Borda count election is often a function of the number of alternatives considered [86]. However, the Borda count will never choose the Condorcet loser [77].

The Borda count is one of the few single-stage voting methods that fails to satisfy the independence of irrelevant alternatives criterion. This failure may be observed, for example, in a three-alternative election when two alternatives are tied for first place. If one voter switches his or her preference ordering for one of the tied alternatives and the third alternative without switching his or her preference ordering for the tied alternatives, the tie may be broken. For the irrelevance of independent alternatives criterion to hold, a switch in preference ordering not involving the tie should not affect the tie [86].

Although the Borda count was initially criticized for its susceptibility to manipulation (before it was known that all non-dictatorial voting systems with at least three possible outcomes are manipulable) later analysts have found it to be a mixed bag. Saari showed that the Borda count is less susceptible to micromanipulation than many other voting systems [88, 89] while Chamberlin demonstrated that the Borda count is more susceptible to coordinated macromanipulation than plurality rule and other positional voting systems [27]. Nurmi places the Borda count and its variations (including its multi-stage variations) at the third level of his hierarchy, noting that although voters submit their entire preference profiles, only binary comparisons are necessary to determine the election result and thus the binary comparison matrix is all the information needed to manipulate the election [78].

## Multi-Stage Methods

Multi-stage procedures use either different choice functions at different stages of the procedure, or one choice function iteratively on diminishing sets of alternatives. The following methods are representative of the multi-stage procedures that have been proposed. All of these methods are Pareto-optimal. In addition, they have the advantage that voters can often vote for a preferred candidate who has little chance of winning without ``wasting'' an opportunity to vote for a more viable second-choice candidate (of course situations still arise where it is in a voter's best interest to vote insincerely). Thus voters are likely to have fewer incentives to vote insincerely with multi-stage procedures than with single-stage procedures.

### Black's Method

Black's method simply selects the Condorcet winner when one exists and the Borda count winner in the absence of a Condorcet winner. This method is monotonic and never selects a Condorcet loser.

### The Runoff Election Procedure

The runoff election procedure (sometimes referred to as majority runoff, plurality runoff, second ballot, two-ballot, or double ballot) is a two-stage procedure. It requires the alternatives to be considered together first. If an alternative receives the majority of votes, it is selected. Otherwise a runoff simple majority election is held between the two alternatives receiving the largest numbers of votes. This method is not monotonic and may select an alternative other than the Condorcet winner when a Condorcet winner exists.

Nurmi considers this procedure relatively difficult to manipulate and classifies it at the fourth level of his preference misrepresentation hierarchy [78]. However, the fact that it is not monotonic indicates that when voters have the necessary information, they will find opportunities for manipulation frequently.

A variation of this procedure used to elect the French National Assembly eliminates all candidates who do not receive a specified threshold of votes on the first ballot. As the second ballot may contain more than two candidates, the winner is the one who receives a plurality of votes [67].

Another variation on this procedure is the exhaustive ballot procedure in which the alternatives with the least votes are eliminated one at a time in a series of elections. This procedure can be time consuming and result in decreasing voter participation with each round of balloting [63].

### Nanson's Borda-Elimination Procedure

Nanson's procedure applies the Borda count iteratively, eliminating the lowest scoring alternative after each round. Unlike the regular Borda count, this procedure will select the Condorcet winner when one exists. It will never select the Condorcet loser; however, it is not monotonic.

### Single Transferable Vote

Figure: Procedure for counting votes in a single transferable vote election

There are many variations on this procedure with different methods for calculating the quota needed for election, different redistribution procedures, and different methods for resolving ties. The procedure used to elect the Cambridge City Council and School Committee uses the Droop threshold to determine the quota needed for election. Any candidate receiving votes greater than the total number of votes divided by one more than the number of seats to be filled is elected. In Cambridge elections, votes are redistributed through a method of controlled randomness. For example if a candidate x receives 5000 votes and it is determined that only 4000 votes are needed to pass the Droop threshold, 1000 excess votes must be redistributed. The ballots for x are numbered and every fifth one is redistributed. (In Cambridge, ballots in each precinct are sorted according to the first choice listed. The piles of ballots for each precinct are merged according to a randomly determined precinct order.) While it is theoretically possible for this method to result in different election outcomes depending on the way the ballots happen to be ordered (due to second- or lower-choice alternatives being unevenly distributed among the ballots), a study by the Center for Voting and Democracy indicates that such outcomes are probably rare. The possibility of differing outcomes can be eliminated completely through the use of a mathematical redistribution system. In this system the excess ballots for candidate x in the above example would be distributed by redistributing one fifth of every ballot cast for x to the second choice indicated on that ballot. This method extends considerably the amount of time necessary for vote counting when ballots are tallied by hand. However, computerized vote-counting systems make mathematical redistribution practical [47].

The use of STV generally results in elections with high average effectiveness because all ballots that can be used to elect a candidate, either as a first-choice or on a transfer, have some degree of effectiveness. Because STV allows for redistribution of surplus votes when multiple candidates are to be elected, a single vote may be effective in helping elect more than one candidate.

Some theorists have criticized STV for its violation of several normative criteria. If the Condorcet winner is not eliminated in an STV election, it will be selected; however, it is possible for the Condorcet winner to be eliminated. Furthermore, this procedure is not monotonic and thus may result in perverse outcomes in which a candidate would be better off with fewer votes [18, 38]. In practice it is extremely difficult to detect violations of monotonicity in STV elections and thus such violations are rarely exploited or challenged [10].

STV requires knowledge of the entire preference profile to be manipulated and thus falls in the fourth level of Nurmi's hierarchy [78]. In addition, to the typical form of manipulation in which voters misrepresent their preference orderings, STV is also vulnerable to manipulation in which voters truncate their preference list and do not reveal their complete preference orderings. Despite the fact that examples of such vulnerability have been provided by Brams and Fishburn [18], literature explaining STV to voters continues to deny that truncation of preferences is ever advantageous [47]. This denial is probably of little consequence, however; as situations in which truncation or any other form of manipulation are advantageous in an STV election are almost impossible to detect [10]. But as Dummett explains, situations may arise in which parties may be able to coordinate successful macromanipulation. He proposes an example in which STV is used to select one of three candidates, a, b, or c:

With detailed and reasonably accurate information about the intentions of the voters, such as can be obtained from well-conducted opinion polls, and with a thorough canvass to identify its own supporters, an organized group such as a political party can...instruct sufficiently many supporters to list a highest to ensure that a is not eliminated at stage 1, and instruct the rest to list b highest, in order to bring about the elimination of a's principal rival c [40].

STV is most vulnerable to such manipulation when it is used for elections in which one candidate is to be selected from a small pool of candidates. When multiple candidates are to be selected or when the pool of candidates is large, obtaining complete preference profiles for all voters and doing the computations necessary to find opportunities for manipulation is likely to be quite difficult.

### Coomb's Procedure

Coomb's procedure is similar to STV; however, the alternatives with the most last place votes are eliminated (rather than the alternatives with the least first-place votes).

This procedure is not monotonic and does not always chose the Condorcet winner when one exists. However, it will not select the Condorcet loser. While STV tends to select the most intensely preferred alternative, Coomb's procedure tends to select the alternative viewed as least intolerable by the majority. It requires knowledge of the entire preference profile to be manipulated and thus falls in the fourth-level of Nurmi's hierarchy [77, 78].

## Utilitarian Methods

Utilitarian voting methods require voters to assign utility values to each alternative. Utility values can be thought of as measures of expected happiness with each alternative on some finite scale. These utilities are aggregated to determine the election outcome. Riker explains the rationale behind these methods:

Majoritarian methods base decision on how many times x is ahead of one other alternative. Positional methods base decision on how many times x is ahead of all other alternatives. Neither bases decision on voters' direct valuation of alternatives, although positional methods are sometimes mistakenly so interpreted. Many writers, however, have argued that the intensity of judgment or direct valuation ought to be incorporated into the decision. The voting method should reveal not only that x is ahead of y, but by how much [86].

These methods do not necessarily select the Condorcet winner when one exists. They also violate the independence of irrelevant alternatives criterion. These methods do not fit cleanly into Nurmi's preference misrepresentation hierarchy because voters are likely to misrepresent the intensity of their preferences using these methods, even if they do not misrepresent their preference orderings. In order to manipulate the election successfully by misrepresenting their preference orderings, voters would need to know not only the entire ordinal preference profile required for Nurmi's fourth level systems, but also information from the cardinal preference profile. However, manipulation may be possible through misrepresentation of preference intensity without any additional information.

Several types of utilitarian methods described by Riker [86] and Mueller [72] are introduced below.

### Direct Aggregation of Cardinal Utility Methods

Several utilitarian methods involve simple mathematical aggregations of cardinal utilities. In the ``summation of cardinal utility'' method the utility values for each alternative are added and the alternative receiving the largest sum wins. In the ``multiplication of utilities'' method the utility values for each alternative are multiplied and the the alternative receiving the largest product wins. In some methods the utilities are fit to some normal scale before they are aggregated. These methods suffer from the fact that it is always in the voters' best interests to inflate their preferences for their most preferred alternatives and deflate their preferences for their least preferred alternatives.

### Demand-Revealing Methods

The demand-revealing method introduced in 1976 by Tideman and Tullock as ``a new and superior process for making social choices'' is one of the most unusual voting methods. The purpose of this system is to motivate people to state truthfully the values they place on public goods. The procedure operates as follows: Each voter offers to pay an amount of money m to obtain a preferred alternative. The amounts of money offered for each alternative are summed, and the alternative with the largest sum is the winner. In order to prevent people from offering more money than they really believe an alternative is worth, those whose offers for the winning alternative exceed the margin of victory must pay a tax equal to their contribution to the victory. This tax is wasted or given to people not involved with the vote so as to prevent its distribution from affecting the way people vote [99].

Riker criticizes this system for promoting inequality by providing an advantage to those whose budgets will be least impacted by paying a tax. He also criticizes it for encouraging coercion in an attempt to minimize the tax [86]. However, Tullock notes that the system need not use real money. Each citizen might be given a certain number of points which he or she may use for paying the voting taxes [101]. He does not comment on the possibility of markets developing for buying and selling these points. In addition, Riker notes that this system cannot be used in secret-ballot elections because it requires public revelation of individual offers in order to assess the taxes [86]. However, cryptographic electronic voting and payment systems might make such a system practical without public revelation of offers.

## Proportional and Semiproportional Representation Systems

Proportional representation (PR) and semiproportional representation systems are designed to promote close correspondence between the proportion of supporters of each party (or other interest group) in the electorate and the proportion of seats held by each party in a governing body. To achieve this goal, these systems require the electorate to be divided into constituencies such that each elects more than one representative. There is a wide variety of methods used to achieve proportional representation, and each succeeds to varying degrees. Although on average PR systems produce results more proportional than produced by plurality voting systems, some PR systems are in reality less proportional than most plurality systems. Several countries have recently adopted mixed-member proportional representation systems (MMP) in which some representatives are elected from single-member districts and others are elected at-large using a PR system [33, 67].

Proportional representation was introduced in the nineteenth century as a way to provide representation for interests that could not be represented when a single representative was elected from each geographic community. After the breakup of the European empires at the beginning of the twentieth century, PR was selected by many countries in order to ensure that the educated minority would be represented in the new governments [6]

The many varieties of proportional representation systems that have been used to elect legislatures around the world can be divided into two categories: list PR (which employs a variation on plurality rule) and single transferable vote. The semiproportional systems all employ a variation on plurality rule. Although the goal of proportional representation might be pursued through adaptations of any of the positional or majoritarian voting methods, only plurality rule and STV have been used in practice.

### List Proportional Representation

List PR is one of the most commonly used voting systems for governmental elections; however, it has never been used in the United States [6]. Although list PR is based on a simple idea, the implementation details of list PR systems are often complicated. These details involve the method used to determine how many seats should be allocated to each party and the method used to determine which individual will fill each seat. In all cases, the underlying decision rule is a variation on plurality rule.

In the simplest case, the entire country is treated as a single constituency, and the legislative seats are allocated in exact proportion to the support for each party among the electorate. However, even in this simple case, the mathematics of the situation may preclude the achievement of perfect proportionality. A country of population P represented by L legislators would ideally select one representative for each P/L voters. But it is unlikely that the vote totals for each party will be exact multiples of P/L, and fractional representatives are not an option. Several methods have been developed to solve this problem both in the case of a single constituency country and in the more usual case where a country is divided into many constituencies.

One of the easiest ways to allocate seats is to establish a quota necessary to win each seat. In this largest remainder method the parties are first allocated one seat for each multiple of the quota they have received. All votes received beyond an even multiple of the quota are a remainder. The remaining seats are allocated to the parties with the largest remainders. There are also more complicated methods, such as the largest average rule, that tend to have more proportional results [63].

The methods used to determine which individual will fill each seat vary in the extent to which they emphasize the influence of parties versus the opinions of individuals. The simplest forms leave the decision entirely up to the party while more complicated systems respect voters' opinions to varying degrees.

In the basic list systems, the parties prepare lists that include as many candidates as there are seats to be filled. The voters select the list for the party they support and deposit it in their ballot envelopes. After the votes are counted and the seats are allocated, each party selects from the top of its list the number of candidates corresponding to the number of seats won. A party winning one seat would select the candidate at the top of its list, a party winning two seats would select the top two candidates, and so on. The candidate at the bottom of the list has almost no chance of being elected [63].

Some countries allow voters to vote either for a party list or for a particular candidate on the list. In Belgium, for example, the vote tallies are added up for all of the candidates who received individual votes. All that receive enough votes to meet the quota are elected. The votes for the party list are then divided among the candidates on that list as follows: The first candidate on the list takes as many votes from the party list pool as are needed to meet the quota. If any votes remain in the pool the next candidate on the list takes as many as are needed to meet the quota, and so on until there are no more votes left in the pool. The more voters who choose to vote for the party list, the more influence the party has on the election result. In practice, the percentage of voters who do not vote for the party list (or take advantage of election laws in some countries that let them cross out candidates on their party list) is generally small [63].

### Single Transferable Vote System of Proportional Representation

The single transferable vote system of proportional representation, also referred to as the quota preferential system and the preference voting system, uses the STV procedure (described in Section ) or one of its variations to promote proportional representation in each constituency. STV has been used in Ireland for most of the twentieth century. It is also used in Malta, Australia, and Cambridge, Massachusetts. Unlike the list PR systems, which are focussed on supporting political parties, STV systems are designed to promote proportional representation by maximizing the effectiveness of every vote, regardless of whether the vote supports a particular party. In practice, this system often results in parties obtaining proportional representation, but this occurs only as a consequence of the voters choosing to vote along party lines [63, 67].

### Limited Vote

The limited vote, a semiproportional representation system used in Spain and Portugal in the 19th and early 20th centuries and in parts of the United Kingdom in the 19th Century, is a plurality rule procedure that elects multiple candidates. However, unlike traditional extensions of the plurality rule for multiple candidates in which each voter may vote for as many candidates as are to be elected, this procedure limits voters to a number of votes less than the number of candidates to be elected. The number of votes is limited to encourage the representation of both majority and minority parties. Under traditional plurality systems, the majority party often supports as many candidates as are to be elected, and party members vote for all the party candidates. Thus it is difficult for minority candidates to be elected. However, in a limited vote system majority party members must either back fewer candidates than are to be elected or split their votes. This gives minority candidates a greater chance of being elected. It also tends to encourage parties to support fewer candidates than would be appropriate given the proportion of the electorate that supports that party. This is due to the fact that if parties over estimate their support, the vote for their candidates will be spread too thinly and most or all of their candidates will lose [63, 67].

### Single Non-Transferable Vote

The single non-transferable vote (SNTV) is a special case of the limited vote in which voters may specify only a single candidate on their ballots, regardless of how many seats are to be filled. This semiproportional method has been used in Japan throughout most of the twentieth century [67]. It is credited with producing results more reflective of the wishes of the voters than are produced by other systems for electing multiple candidates. Because of its simplicity it is well suited for elections in which large parts of the electorate are illiterate. However, SNTV also tends to ``cause stagnation, each party hesitating to run the risk of nominating more candidates than were successful in the previous election.'' It may also cause resentment among voters who do not feel that the system lets them express their preferences fully [63].

### Cumulative Vote

The cumulative vote, a semiproportional system used to elect members of the Illinois State House of Representatives in the first half of the twentieth century, allots each voter a number of votes equal to the number of candidates to be elected. The voters may give one vote each to that number of candidates or accumulate their votes, allocating two or more to one candidate. In Illinois, when voters were to select three candidates they could give ``one vote to each candidate, or one and a half votes to each of two candidates, or three votes to one candidate'' [63]. This system has also been used for British school board elections and for electing corporate boards of directors. The cumulative vote system has many of the same advantages and disadvantages as the limited vote and SNTV systems. In addition, it allows more opportunities for voters to express themselves, but may be too complicated for some voters to understand [63].
